Die Casting Mould Outdoor COB Led Street Light Housing IP65 Waterproof 150 Watt

Product Categories
NingBo Die-Casting Man Technology Co.,ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Die Casting Mould Outdoor COB Led Street Light Housing IP65 Waterproof 150 Watt

Brand Name : DIE CASTING MAN

Model Number : YASL-08-180

Certification : CE, RoHs, ENEC, CB

Place of Origin : China

MOQ : 1pcs

Price : negotiation

Payment Terms : By T/T 30% in advance and 70% after shipment

Supply Ability : 10000PCS/Month.

Delivery Time : 7-30 days base on order quantity

Packaging Details : Carton box with foam

Power : 150W 180W

Material : die casting Aluminum body + glass lens

Net Weight : 4.4kgs

Gross Weight : 5.2kgs

Installation Pipe : φ60mm

Installation Height : 8-12m

Ra : ≥70

Led lifetiem : 50000h

Contact Now

Die Casting Mould Outdoor COB Led Street Light Housing IP65 Waterproof 150 Watt

IP65 Waterproof Outdoor COB led street light 150 watt customisable die-casting mould led street light housing​

Product Description:

Code ZHSL-08-30 ZHSL-08-50 ZHSL-08-80 ZHSL-08-120 ZHSL-08-180
Power 30W 50W 80W 120W 180W
Color Temperature 3000-6500K 3000-6500K 3000-6500K 3000/4000/6500K 3000/4000/6500K
Efficiency ＞120LM/W ＞120LM/W ＞120LM/W ＞120LM/W ＞120LM/W
Voltage AC90-305V 50/60Hz AC90-305V 50/60Hz AC90-305V 50/60Hz AC90-305V 50/60Hz AC90-305V 50/60Hz
Power Factor PF≥0.95 PF≥0.95 PF≥0.95 PF≥0.95 PF≥0.95
CRI(Ra) Ra≥70 Ra≥70 Ra≥70 Ra≥70 Ra≥70
Ambient Temperature -20-50℃ -20-50℃ -20-50℃ -20-50℃ -20-50℃
Ambient Humidity 20%-90%RH 20%-90%RH 20%-90%RH 20%-90%RH 20%-90%RH
Lifetime(hrs) 50000hrs 50000hrs 50000hrs 50000hrs 50000hrs
IP Rate IP66 IP66 IP66 IP66 IP65
Installation Pipe Diameter Φ40mm Φ60mm Φ60mm Φ60mm Φ60mm
Installation Height 4-7m 4-7m 6-8m 10-12m 10-14m
Net Weight 1.8kg 1.8kg 2.8kg 4.4kg 6.2kg
Gross Weight 2.1kg 2.1kg 3.3kg 5.2kg 7.0kg
Packing Size(mm) 445*200*205/2PCS 545*230*120 665*300*145 765*300*145 920*355*150

Luminaire type
A bracket mounted type luminaire for lighting roadways.

Applications
The luminaries can be used for lighting of important roadways, secondary roads, roads in industrial & residential areas etc.

Mounting methods
Suitable for side entry, pole mounting.

Optical system
MOC of optics is borosilicate glass.

LED system
Luminaire luminous flux 16500 lm, luminaire wattage 150W, luminous efficiency of luminaire 110 lm / W, correlated colour temperature ( CCT ) 3000 K-6500K, general colour rendering index ( CRI ) Ra > 80, long life > 50000 burning hours.

Luminaire body
Luminaire body is made up of high pressure die cast aluminium, with side contour, with closed appearance, highly weather resistant, powder-coated.

Die Casting Mould Outdoor COB Led Street Light Housing IP65 Waterproof 150 Watt

Die Casting Mould Outdoor COB Led Street Light Housing IP65 Waterproof 150 Watt
